ImFusion C++ SDK 4.4.0
|
|
ImFusion C++ SDK 4.4.0
|
#include <ImFusion/GUI/SliceIndexOverlay.h>
Renders the current slice number and total slices of the first data in the assigned view eg. More...
Renders the current slice number and total slices of the first data in the assigned view eg.
120/250
The overlay is hidden when the text is empty:
Public Member Functions | |
| SliceIndexOverlay (const ImageView2D &view, AnchorPoint anchor) | |
| Listens to the given view for data changes. Anchors at the given anchor location in the view. | |
| void | setTextColor (const vec4 &color) |
| Sets the color of the text to be rendered. | |
| void | setFontSize (int size) |
| Sets the font size in pt of the text to be rendered. | |
| void | setVisible (bool visible) override |
| Make overlay hidden/visible. | |
| Public Member Functions inherited from ImFusion::InteractiveOverlay | |
| InteractiveOverlay (std::unique_ptr< GlOverlay > overlay, AnchorPoint anchor) | |
| Instantiate a new InteractiveOverlay taking ownership of the underlying GlOverlay. | |
| InteractiveOverlay (GlOverlay &overlay, AnchorPoint anchor) | |
| Instantiate a new InteractiveOverlay referencing the given overlay. | |
| InteractiveOverlay (GlOverlay *overlay, AnchorPoint anchor, bool ownOverlay=true) | |
| const GlOverlay * | overlay () const |
| Get a pointer to the underlying overlay. | |
| GlOverlay * | overlay () |
| Get a pointer to the underlying overlay. | |
| virtual void | setInteraction (std::unique_ptr< OverlayInteraction > interaction) |
| Set an interaction event handler for this overlay. | |
| QRect | rect () const |
| Get position and actual size (including margins) of overlay in viewport coordinates. | |
| void | setMargin (int horizontal, int vertical) |
| Sets the margin in pixels between the border of the drawing area and the border of the overlay content. | |
| int | horizontalMargin () const |
| Gets the horizontal margin in pixels between the border of the drawing area and the border of the overlay content. Default is 2. | |
| int | verticalMargin () const |
| Gets the vertical margin in pixels between the border of the drawing area and the border of the overlay content. Default is 2. | |
| virtual void | setSizeHint (int width, int height) |
| Sets the preferred size of the overlay for a DPI scaling of 1.0. | |
| virtual int | sizeHintWidth () const |
| Gets the preferred width of the overlay. | |
| virtual int | sizeHintHeight () const |
| Gets the preferred height of the overlay. | |
| virtual void | setMinimalSizeHint (int width, int height) |
| Sets the minimal size of the overlay for a DPI scaling of 1.0. | |
| virtual int | minimalSizeHintWidth () const |
| Gets the minimal width of the overlay. | |
| virtual int | minimalSizeHintHeight () const |
| Gets the minimal height of the overlay. | |
| void | setAnchorPoint (AnchorPoint anchorPoint) |
| Set the anchor point of overlay. | |
| AnchorPoint | anchorPoint () const |
| Get the anchor point of overlay. | |
| virtual bool | sceneEvent (QEvent *event) |
| Called by the hosting InteractiveView, default implementation forwards it to the set OverlayInteraction. | |
| GUI::EventResult | handleInputEvent (const GUI::InputEvent &event) override |
| Calls the base interface's version and then continues propagation to sceneEvent(). | |
| Public Member Functions inherited from ImFusion::GUI::ViewOverlay | |
| ViewOverlay (std::unique_ptr< GlOverlay > glOverlay) | |
| Instantiate a new ViewOverlay taking ownership of the underlying GlOverlay which must not be null. | |
| virtual void | render () |
| Calls GlOverlay::render() on the underlying glOverlay() using the current viewport() shrinked by margin(). | |
| const GlOverlay & | glOverlay () const |
| Get a pointer to the underlying overlay. | |
| GlOverlay & | glOverlay () |
| Get a pointer to the underlying overlay. | |
| const GL::Viewport & | viewport () |
| Returns the area where this overlay is rendered. | |
| bool | isVisible () const |
| Returns the visibility of this overlay. | |
| const vec2i & | margin () const |
| Returns the margin in pixels between the border of the drawing area and the border of the overlay content. | |
| void | setMargin (const vec2i &value) |
| Sets the margin in pixels between the border of the drawing area and the border of the overlay content. | |
| vec2i | minimalSizeHint () const |
| Returns the underlying GlOverlay's minimal size hint plus the configured margin(). | |
| vec2i | sizeHint () const |
| Returns the underlying GlOverlay's size hint plus the configured margin(). | |
| void | configure (const Properties *p) override |
| Configure this object instance by de-serializing the given Properties. | |
| void | configuration (Properties *p) const override |
| Serialize the current object configuration into the given Properties object. | |
| Public Member Functions inherited from ImFusion::Configurable | |
| virtual void | configureDefaults () |
| Retrieve the properties of this object, replaces values with their defaults and sets it again. | |
| void | registerParameter (ParameterBase *param) |
| Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration(). | |
| void | unregisterParameter (const ParameterBase *param) |
| Remove the given Parameter or SubProperty from the list of registered parameters. | |
| Configurable (const Configurable &rhs) | |
| Configurable (Configurable &&rhs) noexcept | |
| Configurable & | operator= (const Configurable &) |
| Configurable & | operator= (Configurable &&) noexcept |
| Public Member Functions inherited from ImFusion::SignalReceiver | |
| SignalReceiver ()=default | |
| Default constructor. | |
| SignalReceiver (const SignalReceiver &other) | |
| Copy constructor, does not copy any existing signal connections from other. | |
| SignalReceiver & | operator= (SignalReceiver rhs) |
| Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs. | |
| virtual | ~SignalReceiver () |
| Virtual destructor disconnects from all connected signals. | |
Additional Inherited Members | |
| Public Types inherited from ImFusion::InteractiveOverlay | |
| enum | AnchorPoint { BottomLeft = int(Anchor::BottomLeft) , BottomRight = int(Anchor::BottomRight) , TopLeft = int(Anchor::TopLeft) , TopRight = int(Anchor::TopRight) , Top = int(Anchor::Top) , Bottom = int(Anchor::Bottom) , Left = int(Anchor::Left) , Right = int(Anchor::Right) , Fill = int(Anchor::Fill) } |
| Anchor point of the overlay in the hosting InteractiveView. More... | |
| Public Types inherited from ImFusion::GUI::ViewOverlay | |
| enum class | Anchor { BottomLeft = 0 , BottomRight = 1 , TopLeft = 2 , TopRight = 3 , Top = 4 , Bottom = 5 , Left = 6 , Right = 7 , Fill = 8 } |
| Anchor point of the overlay in the parent View. More... | |
| enum class | LayoutDirection { Horizontal = 0 , Vertical = 1 } |
| Layout direction when stacking multiple ViewOverlays at the same anchor. | |
| Signals inherited from ImFusion::InteractiveOverlay | |
| void | anchorPointChanged (InteractiveOverlay::AnchorPoint anchorPoint) |
| Public Attributes inherited from ImFusion::GUI::ViewOverlay | |
| Signal | signalUpdateRequested |
| Emitted in order to notify the parent Display that it's contents have changed and need to be re-rendered. | |
| Signal | signalLayoutNeeded |
| Emitted whenever the size hints or margin have changed to notify the parent View that it needs to perform overlay layouting. | |
| Public Attributes inherited from ImFusion::Configurable | |
| Signal | signalParametersChanged |
| Emitted whenever one of the registered Parameters' or SubPropertys' signalValueChanged signal was emitted. | |
| Protected Member Functions inherited from ImFusion::InteractiveOverlay | |
| void | setOverlay (GlOverlay *overlay, bool ownOverlay) |
| Update the internal GlOverlay. | |
| Protected Member Functions inherited from ImFusion::SignalReceiver | |
| void | disconnectAll () |
| Disconnects all existing connections. | |
| Protected Attributes inherited from ImFusion::InteractiveOverlay | |
| GlOverlay * | m_overlay = nullptr |
| Underlying GlOverlay. | |
| std::unique_ptr< OverlayInteraction > | m_interaction |
| Interaction class to handle overlay events. | |
| AnchorPoint | m_anchorPoint |
| Anchor point within parent view. | |
| bool | m_ownOverlay = true |
| Flag whether m_overlay is owned by this instance. | |
| Protected Attributes inherited from ImFusion::GUI::ViewOverlay | |
| std::unique_ptr< GlOverlay > | m_glOverlay |
| GL::Viewport | m_viewport = {} |
| vec2i | m_margin = vec2i::Zero() |
| bool | m_isVisible = true |
| Protected Attributes inherited from ImFusion::Configurable | |
| std::vector< Param > | m_params |
| List of all registered Parameter and SubProperty instances. | |
| Properties inherited from ImFusion::InteractiveOverlay | |
| InteractiveOverlay::AnchorPoint | anchorPoint |
|
overridevirtual |
Make overlay hidden/visible.
Reimplemented from ImFusion::GUI::ViewOverlay.
