Detailed Description

Base class for user input events in a graphical user interface (GUI).

By design, all InputEvents are immutable to make reasoning over the program logic easier. In contrast to many other event messaging frameworks the back-channel for notifying a sender whether a receiver "accepted" an event and/or how it should continue propagation is not the event itself but the EventResult struct serving as return value of a handleInputEvent() function.

Note: All coordinates/positions held by an InputEvent are in the rendering coordinate system of the Display instance emitting the event. This means that the origin is in the lower left corner of the viewport, in the same fashion as done by OpenGL.

See also: InputEventHelpers

Public Types
enum class	KeyboardModifier { None = 0 , Shift = 1 << 0 , Control = 1 << 1 , Alt = 1 << 2 , Meta = 1 << 3 }
	Bitfield enumeration to describe modifier keys on the keyboard. More...

using	LocalToGlobalCoordMapping = std::function<vec2(const vec2&)>
	Typedef for a function to map from event coordinates to global coordinates if applicable.

Public Member Functions
	InputEvent (Flags< KeyboardModifier > modifiers, LocalToGlobalCoordMapping mappingFunction=nullptr)
	Constructor for the InputEvent base class.

const KeyEvent *	asKeyEvent () const
	Convenience function to dynamic_cast this instance to a KeyEvent.

const MouseEvent *	asMouseEvent () const
	Convenience function to dynamic_cast this instance to a MouseEvent.

const TouchEvent *	asTouchEvent () const
	Convenience function to dynamic_cast this instance to a TouchEvent.

const ContextMenuEvent *	asContextMenuEvent () const
	Convenience function to dynamic_cast this instance to a ContextMenuEvent.

const Flags< KeyboardModifier > &	modifiers () const
	Returns the list of pressed keyboard modifier keys.

vec2	mapToGlobalCoord (const vec2 &localCoord) const
	Converts the given localCoord to the global coordinate system of the underlying windowing system if applicable.

const LocalToGlobalCoordMapping &	localToGlobalMappingFunction () const

Protected Attributes
Flags< KeyboardModifier >	m_modifiers = KeyboardModifier::None

LocalToGlobalCoordMapping	m_localToGlobalMappingFunction

Member Enumeration Documentation

◆ KeyboardModifier

enum class KeyboardModifier

strong

Bitfield enumeration to describe modifier keys on the keyboard.

Note: According to the Apple Human Interface Guidelines the Command key is to be used for almost all keyboard shortcuts. All other platforms use the Control key instead. Therefore, this enumeration swaps the meaning of Control and Meta for MacOS where the Control modifier corresponds to the Command key and the Meta modifier to the Control keys.

Enumerator
None	None of the modifier keys is pressed.
Shift	Shift key is pressed.
Control	Control key is pressed; except for MacOS: Command key is pressed.
Alt	Alt key is pressed.
Meta	Meta key is pressed; except for MacOS: Control key is pressed.

Constructor & Destructor Documentation

◆ InputEvent()

InputEvent	(	Flags< KeyboardModifier >	modifiers,
		LocalToGlobalCoordMapping	mappingFunction = nullptr )

explicit

Constructor for the InputEvent base class.

Parameters

modifiers	List of pressed keyboard modifier keys.
mappingFunction	Optional mapping function used by mapToGlobalCoord() to convert event coordinates to global coordinates if the underlying windowing system supports it; mapToGlobalCoord() will use the identity function if empty.

Member Function Documentation

◆ mapToGlobalCoord()

vec2 mapToGlobalCoord ( const vec2 & localCoord ) const

Converts the given localCoord to the global coordinate system of the underlying windowing system if applicable.

If the original source of the event does not support global coordinates it will return the input value unchanged.

Deprecated: This function is merely provided as a deprecation layer to make the Qt-based view framework work with the new ImFusion::GUI framework. Do not rely on this functionality in new code because it may be removed in the future.

◆ localToGlobalMappingFunction()

const LocalToGlobalCoordMapping & localToGlobalMappingFunction ( ) const

inline

Deprecated: This function is merely provided as a deprecation layer to make the Qt-based view framework work with the new ImFusion::GUI framework. Do not rely on this functionality in new code because it may be removed in the future.

The documentation for this class was generated from the following file:

ImFusion/GUI/InputEvent.h
