Detailed Description

Manipulator setting the direction of spline based curved views.

Public Types
enum	InteractionMode { InteractionNone = 0 , InteractionCreate = 1 , InteractionMoveCorner = 2 , InteractionMoveEdge = 4 , InteractionMoveSide = 8 , InteractionMoveCenter = 16 , InteractionScale = 32 , InteractionRotate = 64 , InteractionDirectionChange = 128 }

Public Types inherited from PointBasedAnnotationManipulator
enum	InteractionMode { InteractionNone = 0 , InteractionCreate = 1 , InteractionMove = 2 , InteractionAdd = 4 , InteractionRemove = 8 , InteractionEdit = 16 , InteractionScale = 32 , InteractionRotate = 64 }

enum class	VolumeViewPickingMode { On , Off , Automatic }
	Enumeration to describe when PointBasedAnnotationManipulator should perform 3D position picking in GlVolumeViews. More...

Public Types inherited from GlObject
enum	RenderingOrderGroup { RenderingGroupRest , RenderingGroupMesh , RenderingGroupManipulator }
	Enumeration to determine rendering order of GlObjects in GlSliceView and GlVolumeView. More...

Public Member Functions
void	setInteractionMode (CurvedViewSplineManipulator::InteractionMode mode, bool finalize=true)

	CurvedViewSplineManipulator (GlCurvedViewSpline &annotation)

bool	sceneEvent (QEvent *event, const GlView &view) override

void	setVisible (bool visible) override
	Set object visibility.

bool	visible ()

void	draw (const GlView &view) override
	Draw the object in 3D space.

void	draw2D (const GlView &view)

void	draw3D (const GlView &view)

void	drawCircle (GL::FixedFunctionPipeline &ffp, const GL::ViewState &state)

void	drawHandle (GL::FixedFunctionPipeline &ffp, const GL::ViewState &state)

void	setCircle (const vec3 &pos)

Geometry::AlignedBox	bounds () const override
	Get the axis-aligned bounding box of this GlObject in world space.

std::string	typeName () const override
	Return unique identifier for this object class used for serialization.

void	setMainWindow (MainWindowBase *mw)

void	setInteractive (InteractiveObject *obj)

Public Member Functions inherited from PointBasedAnnotationManipulator
	PointBasedAnnotationManipulator (GlPointBasedAnnotation &annotation)

bool	sceneEvent (QEvent *event, const GlView &view) override

virtual bool	sceneEvent3D (const MouseEvent &ev, const GlVolumeView &view)

bool	get3dPos (const MouseEvent &ev, const GlVolumeView &view, vec3 &result)

virtual void	setInteractionMode (PointBasedAnnotationManipulator::InteractionMode mode, bool finalize=true)
	Sets the interaction mode.

InteractionMode	interactionMode () const
	Returns the interactions mode.

void	setAllowedInteractions (Flags< PointBasedAnnotationManipulator::InteractionMode > allowedInteractions)
	Sets allowed interactions.

Flags< PointBasedAnnotationManipulator::InteractionMode >	allowedInteractions () const
	Returns the allowed interactions.

void	setHovering (bool hovering)
	Sets the hovering behavior (i.e.

bool	hovering () const
	Returns whether hovering support is enabled.

void	reset ()
	Resets all parameters to their default value.

void	setPoints (const std::vector< vec3 > &points)

void	setAxisManip (int axis)
	Set axis along which points can be moved. Point coordinates will be fixed on other axes. Only applies to move and edit interactions.

void	clearAxisManip ()
	Make point movable along all axes.

void	setBounds (double x0, double x1, double y0, double y1, double z0, double z1)
	Set bounds for allowed point coordinates.

void	clearBounds ()
	Clear bounds.

MouseEvent::Button	lastButton () const
	Return button with which last interaction was performed.

virtual void	setHoverCursor ()
	Sets cursor to open hand.

virtual void	setInteractionCursor ()
	Sets cursor to closed (grabbing) hand.

void	resetCursor ()
	Resets cursor to default.

void	setInteractiveAnnotation (InteractiveAnnotation *annot)

bool	requiresFocus () override
	Derived classes that need priority scene events can override this.

void	setVolumeViewPickingMode (VolumeViewPickingMode pickingMode)

void	setChangeCursorOnEdit (bool change)

Qt::Key	finishCreationKey () const

void	setFinishCreationKey (Qt::Key key)

Qt::Key	abortCreationKey () const

void	setAbortCreationKey (Qt::Key key)

Public Member Functions inherited from Manipulator
void	addListener (ManipulatorListener *listener)

void	removeListener (const ManipulatorListener *listener)

virtual void	openContextMenu (QPoint pos, QPoint globalPos, Qt::KeyboardModifiers modifiers)

GUI::EventResult	handleInputEvent (const GUI::InputEvent &event, const GUI::View &view) override
	This function is called by sources of input events in order to dispatch them to the handlers.

Public Member Functions inherited from GlObject
virtual Geometry::AlignedBox	boundsSpherical () const
	Get the spherical bounds of this GlObject in world space.

virtual void	setMatrix (const mat4 &m)
	Set the modelview matrix of this object.

virtual const mat4 &	matrix () const
	Return the modelview matrix.

virtual bool	visible () const
	Return object visibility.

virtual void	setAlwaysVisible (bool alwaysVisible)
	Set if object is always visible.

virtual bool	alwaysVisible () const
	Return if object is always visible.

RenderingOrderGroup	renderingOrder () const
	Return current rendering order value for this GlObject.

void	setRenderingOrder (RenderingOrderGroup group)
	Set rendering order value for this GlObject.

void	setDraw3DIn2DView (bool draw3DIn2DView)

void	configure (const Properties *p) override
	Configure this object instance by de-serializing the given Properties.

void	configuration (Properties *p) const override
	Serialize the current object configuration into the given Properties object.

Public Member Functions inherited from Configurable
virtual void	configureDefaults ()
	Retrieve the properties of this object, replaces values with their defaults and sets it again.

void	registerParameter (ParameterBase *param)
	Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration().

void	unregisterParameter (const ParameterBase *param)
	Remove the given Parameter or SubProperty from the list of registered parameters.

	Configurable (const Configurable &rhs)

	Configurable (Configurable &&rhs) noexcept

Configurable &	operator= (const Configurable &)

Configurable &	operator= (Configurable &&) noexcept

Additional Inherited Members
Public Attributes inherited from PointBasedAnnotationManipulator
Signal< const PointBasedAnnotationManipulator * >	signalCreatingFinished
	Emitted when the manipulator leaves the InteractionCreate mode.

Public Attributes inherited from Configurable
Signal	signalParametersChanged
	Emitted whenever one of the registered Parameters' or SubPropertys' `signalValueChanged` signal was emitted.

Protected Member Functions inherited from PointBasedAnnotationManipulator
virtual InteractionMode	selectInteraction (const MouseEvent &ev, bool hitLine)
	Selects the next interaction given the mouse event and hitLine.

virtual bool	onCreate (const MouseEvent &event, vec3 &X, bool &update, const GlView &view)
	Handler for mouse events in the InteractionCreate mode.

virtual bool	onMove (const MouseEvent &event, vec3 &X, bool &update)
	Handler for mouse events in the InteractionMove mode.

virtual bool	onAdd (const MouseEvent &event, vec3 &X, bool &update)
	Handler for mouse events in the InteractionAdd mode.

virtual bool	onRemove (const MouseEvent &event, vec3 &X, bool &update)
	Handler for mouse events in the InteractionRemove mode.

virtual bool	onEdit (const MouseEvent &event, vec3 &X, bool &update, const GlView &view)
	Handler for mouse events in the InteractionEdit mode.

virtual bool	onScale (const MouseEvent &event, vec3 &X, bool &update)
	Handler for mouse events in the InteractionScale mode.

virtual bool	onRotate (const MouseEvent &event, vec3 &X, bool &update, const GlView &view)
	Handler for mouse events in the InteractionRotate mode.

void	finalizeInteraction ()

virtual bool	pickingNeeded ()

bool	computeCursorMeshIntersection (const MouseEvent &event, const GlVolumeView &view, const GlMesh *mesh, vec3 &result)

void	enablePicking (GlVolumeView &view)

void	disablePicking ()

Protected Member Functions inherited from Manipulator
void	notifyListeners (void *eventData)

Protected Attributes inherited from PointBasedAnnotationManipulator
GlPointBasedAnnotation &	m_annotation

GlObject::RenderingOrderGroup	m_originalAnnotationRenderingOrder = GlObject::RenderingGroupRest

vec3	m_pos0

int	m_selectedPoint

InteractionModeWrapper	m_interactionMode

Flags< InteractionMode >	m_allowedInteractions

bool	m_hovering

std::vector< vec3 >	m_points0

int	m_axisManip

bool	m_useBounds

double	m_bounds [6]

bool	m_changeCursorOnEdit = false

bool	m_interactionCursor = false

bool	m_hoverCursor = false

bool	m_wantsFocus

bool	m_suppressNextContextMenuEvent
	If true, the context menu is not shown after right mouse release (usually set after a move)

bool	m_isPressed = false

VolumeViewPickingMode	m_3dPickingMode = VolumeViewPickingMode::On

InteractiveAnnotation *	m_interactiveAnnotation

vec3	m_center

vec2i	m_mouse0

vec2i	m_mouse

vec3	m_depthAxis

vec3	m_xAxis

vec3	m_yAxis

std::unique_ptr< GlVolumeView::PickingToken >	m_pickingToken

std::map< GlMesh *, int >	m_originalMeshPickingModes

MouseEvent::Button	m_lastButton

Qt::Key	m_abortCreationKey

Qt::Key	m_finishCreationKey

Protected Attributes inherited from GlObject
mat4	m_matrix = mat4::Identity()
	Modelview transformation matrix of this object.

bool	m_visible = true
	Object visibility.

bool	m_alwaysVisible = false
	Object always visible.

bool	m_draw3DIn2DView
	Draw 3D objects in 2D views. This is to render 3D objects in projective 2D views. Property is not serialized.

RenderingOrderGroup	m_renderingOrder = RenderingGroupRest

Protected Attributes inherited from Configurable
std::vector< Param >	m_params
	List of all registered Parameter and SubProperty instances.

Member Function Documentation

◆ sceneEvent()

bool sceneEvent	(	QEvent *	event,
		const GlView &	view )

overridevirtual

Implements Manipulator.

◆ setVisible()

void setVisible ( bool visible )

overridevirtual

Set object visibility.

Reimplemented from GlObject.

◆ draw()

void draw ( const GlView & view )

overridevirtual

Draw the object in 3D space.

Implements GlObject.

◆ bounds()

Geometry::AlignedBox bounds ( ) const

inlineoverridevirtual

Get the axis-aligned bounding box of this GlObject in world space.

Return an empty (default-constructed) AlignedBox object if the GlObject does not reside in world space.

Implements GlObject.

◆ typeName()

std::string typeName ( ) const

inlineoverridevirtual

Return unique identifier for this object class used for serialization.

Implements GlObject.

The documentation for this class was generated from the following file:

ImFusion/GUI/CurvedViewSplineManipulator.h
