#include <ImFusion/Vision/StereoImageStreamDataController.h>
Data Controller for StereoImageStream. More...
Data Controller for StereoImageStream.
Shows StereoImageStream instances in ImageView2D Currently, there is no display handler for StereoImageSet, so only ImageStreamData from both substreams is shown.
Public Member Functions | |
| StereoImageStreamDataController (StereoImageStream *ss) | |
| Public Member Functions inherited from ImFusion::DataController | |
| std::string | title () const override |
| Returns the shown widget title if the controller is shown in a mode that supports this (e.g. | |
| std::string | factoryName () const |
| Returns the name used to identify this DataController in the factory. | |
| void | setFactoryName (const std::string &factoryName) |
| Sets the name used to identify this DataController in the factory. | |
| std::vector< Location > | supportedLocations () const override |
| Returns the list of locations in which this controller is allowed to be placed by the parent MainWindowBase. | |
| Location | preferredLocation () const override |
| Returns the preferred location in which the parent MainWindowBase should place this controller. | |
| Public Member Functions inherited from ImFusion::Controller | |
| void | setMainWindowBase (MainWindowBase *mw) |
| Complete the initialization by providing the parent MainWindowBase instance hosting the controller by setting m_main and m_disp and eventually call init(). | |
| virtual void | onVisibleDataChanged (const DataList &) |
| Called by MainWindowBase in the case that the currently visible data has changed. | |
| virtual void | onLocationChanged (Location newLocation) |
| Callback function called by the parent MainWindowBase/ControllerDecorator whenever the place was changed. | |
| Location | location () const |
| Convenience function to query the current controller Location from the parent ControllerDecorator. | |
| ControllerDecorator * | getDecorator () const |
| Convenience function to return m_main->getControllerDecorator(this) if m_main is set or nullptr otherwise. | |
| template<typename T> | |
| T * | getDecorator () const |
| Convenience function to dynamic_cast the return value of getDecorator() to a derived type. | |
| Public Member Functions inherited from ImFusion::Configurable | |
| virtual void | configure (const Properties *p) |
| Configure this object instance by de-serializing the given Properties. | |
| virtual void | configuration (Properties *p) const |
| Serialize the current object configuration into the given Properties object. | |
| virtual void | configureDefaults () |
| Retrieve the properties of this object, replaces values with their defaults and sets it again. | |
| void | registerParameter (ParameterBase *param) |
| Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration(). | |
| void | unregisterParameter (const ParameterBase *param) |
| Remove the given Parameter or SubProperty from the list of registered parameters. | |
| Configurable (const Configurable &rhs) | |
| Configurable (Configurable &&rhs) noexcept | |
| Configurable & | operator= (const Configurable &) |
| Configurable & | operator= (Configurable &&) noexcept |
| Public Member Functions inherited from ImFusion::SignalReceiver | |
| SignalReceiver ()=default | |
| Default constructor. | |
| SignalReceiver (const SignalReceiver &other) | |
| Copy constructor, does not copy any existing signal connections from other. | |
| SignalReceiver & | operator= (SignalReceiver rhs) |
| Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs. | |
| virtual | ~SignalReceiver () |
| Virtual destructor disconnects from all connected signals. | |
Static Public Member Functions | |
| static bool | createCompatible (const DataList &data, DataController **a=nullptr) |
| Static Public Member Functions inherited from ImFusion::DataController | |
| static bool | createCompatible (const DataList &, DataController **=0) |
| Factory interface for DataControllers: If data is compatible with data controller return true. | |
Protected Member Functions | |
| void | init () override |
| Two-step initialization function to be implemented by subclasses. | |
| void | clean () |
| void | onSelectedDataChanged (const DataList &data) override |
| Called by MainWindowBase in the case that the selection in the data model has changed. | |
| void | syncZoom (const ImageView2D *src, ImageView2D *dst) |
| Protected Member Functions inherited from ImFusion::DataController | |
| virtual bool | supportsToolBar () const |
| Subclasses can return true if they support showing their GUI in Location::ToolBar. | |
| Protected Member Functions inherited from ImFusion::SignalReceiver | |
| void | disconnectAll () |
| Disconnects all existing connections. | |
Additional Inherited Members | |
| Public Types inherited from ImFusion::Controller | |
| enum class | Location : int { Unknown = -1 , Naked = 0 , PrimaryDock = 1 , SecondaryDock = 2 , Detached = 3 , ToolBar = 4 , UserLocation = 100 } |
| Enumeration of possible placement/decoration options of a Controller. More... | |
| Public Attributes inherited from ImFusion::Controller | |
| Signal | signalTitleChanged |
| Signal emitted when the title() has changed. | |
| Public Attributes inherited from ImFusion::Configurable | |
| Signal | signalParametersChanged |
| Emitted whenever one of the registered Parameters' or SubPropertys' signalValueChanged signal was emitted. | |
| Protected Attributes inherited from ImFusion::DataController | |
| std::string | m_factoryName |
| Protected Attributes inherited from ImFusion::Controller | |
| MainWindowBase * | m_main = nullptr |
| The parent MainWindowBase instance hosting this Controller. | |
| DisplayWidgetMulti * | m_disp = nullptr |
| The main DisplayWidget instance, convenience shortcut for m_main->display(). | |
| Protected Attributes inherited from ImFusion::Configurable | |
| std::vector< Param > | m_params |
| List of all registered Parameter and SubProperty instances. | |
|
overrideprotectedvirtual |
Two-step initialization function to be implemented by subclasses.
This function is called by setMainWindowBase() after the m_disp and m_main attributes have been set and hence a complete initialization of the controller is possible at this point.
Reimplemented from ImFusion::DataController.
|
overrideprotectedvirtual |
Called by MainWindowBase in the case that the selection in the data model has changed.
Reimplemented from ImFusion::Controller.
