Detailed Description

Image data streamed from a streaming device.

Can contain one or more images, each represented by a SharedImage.

If multiple images are present, they are assumed to be from the same acquisition time and represent two different views, e.g. two images from a stereo camera, or a B-Mode and color Doppler image from an ultrasound device.

Public Member Functions
	ImageStreamData (Stream *stream)
	Creates an empty ImageStreamData object with the given stream.

	ImageStreamData (Stream *stream, SharedImageSet &&imageSet)
	Moves the images and (possibly per element) components into the newly created object.

	ImageStreamData (Stream *stream, std::unique_ptr< SharedImage > &&img)
	Moves the single image into the newly created object.

	ImageStreamData (Stream *stream, const std::shared_ptr< SharedImage > &img)
	Shallow-copies the single image into the newly created object.

	ImageStreamData (Stream *stream, const std::shared_ptr< const SharedImage > &img)
	Shallow-copies the single image into the newly created object.

	ImageStreamData (Stream stream, MemImage img)
	Deprecated constructor. Creates an ImageStreamData object with the given stream and image.

virtual void	setImageSet (const SharedImageSet &imageSet)
	Sets the images and (possibly per element) components into this object, replacing all existing images and components.

virtual void	setImages (const std::vector< std::shared_ptr< const SharedImage > > &sharedImages)
	Sets the images into this object, replacing all existing images. Does not modify components.

virtual std::vector< std::shared_ptr< const SharedImage > >	images2 () const
	Return all images contained in sample.

std::shared_ptr< SharedImageSet >	shallowCloneToSharedImageSet () const
	Return all images and (possibly per element) DataComponents contained in sample.

std::unique_ptr< StreamData >	clone () const override

int	size () const
	Return the number of images in the stream data.

bool	containsGlImage () const
	Returns whether any of the images contains an OpenGL image and thus requires synchronization if moved to a thread different from the signaling thread.

const DataComponentList &	components (int i) const
	Returns the DataComponents associated to the element with that index.

const DataComponentList &	components () const
	Returns the list of DataComponents for this data.

DataComponentList &	components ()
	Returns the list of DataComponents for this data.

Public Member Functions inherited from StreamData
virtual Stream *	stream () const
	Returns the stream object which updates this data.

virtual unsigned long long	timestampDevice () const
	Timestamp in milliseconds. Set by the streaming device.

virtual void	setTimestampDevice (unsigned long long time)
	Set timestamp provided by the streaming device, in milliseconds.

virtual unsigned long long	timestampArrival () const
	Timestamp in milliseconds. Based on message's arrival time.

virtual void	setTimestampArrival (std::chrono::system_clock::time_point time)
	Set the system time when this streamData was arrived. It will be stored in milliseconds relative to epoch time.

virtual void	setTimestampArrival (unsigned long long time)
	Set arrival timestamp manually, in milliseconds.

const DataComponentList &	components () const
	Returns the list of DataComponents for this data.

DataComponentList &	components ()
	Returns the list of DataComponents for this data.

template<typename StreamDataClass>
const StreamDataClass *	typed () const

Public Member Functions inherited from ElementwiseDataComponentData
ElementwiseDataComponentList &	elementwiseComponents ()
	Returns elementwise data component list.

const ElementwiseDataComponentList &	elementwiseComponents () const
	Returns elementwise data component list.

DataComponentList &	mutableComponents (int i)
	Returns the DataComponents associated to the element with that index, creating it if necessary.

const DataComponentList &	components (int i) const
	Returns the DataComponents associated to the element with that index.

Protected Attributes
std::vector< std::shared_ptr< const SharedImage > >	m_sharedImages

Protected Attributes inherited from StreamData
Stream *	m_stream
	The stream object which updates this data.

unsigned long long	m_timestampDevice
	Timestamp of the streaming device, in milliseconds.

unsigned long long	m_timestampArrival
	Timestamp when the data is received in ImFusion framework, in milliseconds.

DataComponentList	m_dataComponentList
	The list of DataComponents for this StreamData.

Protected Attributes inherited from ElementwiseDataComponentData
ElementwiseDataComponentList	m_elementwiseComponents
	Encodes elementwise data components.

Additional Inherited Members
Protected Member Functions inherited from StreamData
	StreamData (const StreamData &other)=default

	StreamData (Stream *stream)

	StreamData (Stream *stream, DataComponentList &&components)

Constructor & Destructor Documentation

◆ ImageStreamData()

ImageStreamData	(	Stream *	stream,
		MemImage *	img )

Deprecated constructor. Creates an ImageStreamData object with the given stream and image.

Deprecated: "Use one of the other overloads instead"

Member Function Documentation

◆ setImageSet()

virtual void setImageSet ( const SharedImageSet & imageSet )

virtual

Sets the images and (possibly per element) components into this object, replacing all existing images and components.

Reimplemented in StereoImageStreamData.

◆ setImages()

virtual void setImages ( const std::vector< std::shared_ptr< const SharedImage > > & sharedImages )

virtual

Sets the images into this object, replacing all existing images. Does not modify components.

Reimplemented in StereoImageStreamData.

◆ clone()

std::unique_ptr< StreamData > clone ( ) const

overridevirtual

Implements StreamData.

◆ containsGlImage()

bool containsGlImage ( ) const

Returns whether any of the images contains an OpenGL image and thus requires synchronization if moved to a thread different from the signaling thread.

Cf. OpenGL Core Spec Chapter 5.3: "Shared Objects and Multiple Contexts > Propagating Changes to Objects".

OpenGl context synchronization example:

// Simplified example without thread safety for `fence` and `imageDataForOtherThread`
std::optional<GL::SyncObject> fence;
std::shared_ptr<const ImageStreamData> imageDataForOtherThread;

// in signal callback
if (GL::ContextManager::hasCurrent() && imageData->containsGlImage())
{
    fence = GL::SyncObject();
    GL::flush();
}
imageDataForOtherThread = imageData;

// in consumer thread
if (fence)
{
    fence->wait();
}
// Now it is safe to access the images in imageDataForOtherThread

See also: GL::SyncObject

The documentation for this class was generated from the following file:

ImFusion/Stream/ImageStreamData.h
