Detailed Description

Widget and scrollbar for handling selection and playback of data.

If more than one data is selected, the selection of all of them can be handled simultaneously as long as they have the same size as the first selected Data.

Classes
class	PlaybackWrapper
	This class provides an interface for creating wrappers that allow playback functionality to a type. More...

Public Types
enum class	InputMode { Manual , VisibleData , DataWidgetSelection }
	Enumeration of modes how to determine which datasets are used as input data to operate on by the SelectionWidget. More...

enum class	LockMode { None , Single , First , Last }
	Enumeration of modes how the selection changes with the focus. More...

Public Slots
void	onSelFocus (int val)
	Sets the focus to val - 1

void	onSelFirst ()

void	onSelLast ()

void	onSelAll ()

void	onSelNone ()

void	onSelSkip (int val)

void	onFirstChanged (int val)

void	onLastChanged (int val)

void	onSelLock (int val)

void	onDisplayWidgetLayoutChanged ()

void	onSyncFocus ()

void	onPlay ()

void	onStop ()

void	onLoopToggled ()

void	onPlaySelectedToggled ()

bool	dataHasNewSelection (ImFusion::Selectable *data)

void	deleteCachedSelection (ImFusion::Selectable *data)

void	showFocusLabel (bool show)
	Show/hide focus label showing the current index.

Public Slots inherited from ExpandableGroupBox
void	expand ()
	Expands the group box.

void	collapse ()
	Collapses the group box.

void	setExpanded (bool expanded)
	Expands or collapses the group box (default: expanded)

void	setResizable (bool isResizable)
	Makes the group box vertical resizable (default: disabled)

void	setTitle (const QString &title)
	Sets the title of the group box.

void	setIcon (const QIcon &icon)
	Sets the icon of the group box.

void	clearAndDeleteLater ()

void	setVisible (bool visible) override

void	addAction (QAction *action)
	Adds a new action to the right side of the expand/collapse button.

void	removeAction (QAction *action)
	Removes an action that was previously added with addAction.

std::vector< QAction * >	actions ()
	Lists all actions.

void	addPage (QWidget *widget)
	Calls setWidget if no containing widget is set, does nothing otherwise (required by the Qt designer plugin)

Public Member Functions
	SelectionWidget (MainWindowBase *mw)

void	initFromGlobalSettings ()
	Initializes the local configuration such as the inputMode() from global settings.

void	update ()
	Updates widget with data selection and changes GUI accordingly.

void	setInputData (const std::vector< Selectable * > &input)
	Explicitly define what datasets the SelectionWidget should operate on.

const std::vector< Selectable * > &	inputData ()
	Returns the datasets the Selection widget is currently operating on.

InputMode	inputMode () const
	Returns the source which defines which datasets are configured by the SelectionWidget.

void	setInputMode (InputMode value, bool storeInGlobalSettings=false)
	Sets the source which defines which datasets are configured by the SelectionWidget.

LockMode	lockMode () const
	Returns the lock mode of the selection with respect to the focus.

void	setLockMode (LockMode mode)
	Sets the lock mode of the selection with respect to the focus.

SelectionScrollBar &	scrollBar ()
	Return the SelectionScrollBar hosted next to this widget.

void	setPlaySelected (bool selectedOnly)
	Set whether only selected frames should be played.

bool	isPlaying ()

void	stopPlayback (Data *data)
	If data is currently playing through a playback wrapper, attempt to stop it.

Public Member Functions inherited from ExpandableGroupBox
	ExpandableGroupBox (QWidget *parent=0)
	Creates an empty group box.

QSize	sizeHint () const override

void	setWidget (QWidget *widget)
	Sets the contained widget.

QWidget *	widget ()
	Returns the contained widget if any or nullptr otherwise.

QString	title () const

QIcon	icon () const

bool	isExpanded () const

bool	isResizable () const

void	setCollapsible (bool collapsible)
	Sets if box is collapsible.

bool	isCollapsible ()
	Returns if box is collapsible.

void	setDraggable (bool value)
	Sets the flag whether the box is draggable with the mouse when clicking on the top button.

bool	isDraggable () const
	Returns the flag whether the box is draggable with the mouse when clicking on the top button.

int	count () const
	Returns 1 if widget is set, 0 otherwise (required by the Qt designer plugin)

int	currentIndex () const
	Returns 0 (required by the Qt designer plugin)

Public Member Functions inherited from SignalReceiver
	SignalReceiver ()=default
	Default constructor.

	SignalReceiver (const SignalReceiver &other)
	Copy constructor, does not copy any existing signal connections from other.

SignalReceiver &	operator= (SignalReceiver rhs)
	Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs.

virtual	~SignalReceiver ()
	Virtual destructor disconnects from all connected signals.

Static Public Member Functions
static void	registerPlaybackWrapper (std::unique_ptr< PlaybackWrapper > wrapper)
	Adds a wrapper for figuring out playback on a Data object.

Additional Inherited Members
Signals inherited from ExpandableGroupBox
void	expansionChanged (bool expanded)

void	resizableChanged (bool isResizable)

void	titleChanged (QString title)

void	iconChanged (QIcon icon)

void	actionAdded (QAction *action)

void	actionRemoved (QAction *action)

Protected Member Functions inherited from SignalReceiver
void	disconnectAll ()
	Disconnects all existing connections.

Properties inherited from ExpandableGroupBox
QString	title

QIcon	icon

bool	expanded

bool	resizable

Member Enumeration Documentation

◆ InputMode

enum class InputMode

strong

Enumeration of modes how to determine which datasets are used as input data to operate on by the SelectionWidget.

Enumerator
Manual	The datasets are solely defined by the user through calling setInputData().
VisibleData	Listen to the DisplayWidget of the parent MainWindowBase and use the currently visible datasets.
DataWidgetSelection	Listen to the DataWidget of the parent MainWindowBase and use its current selection.

◆ LockMode

enum class LockMode

strong

Enumeration of modes how the selection changes with the focus.

Enumerator
None	Focus has no effect on the rest of the selection.
Single	Both first and last are locked to the focus.
First	The first parameter of the selection is locked to the focus.
Last	The last parameter of the selection is locked to the focus.

Member Function Documentation

◆ setInputData()

void setInputData ( const std::vector< Selectable * > & input )

Explicitly define what datasets the SelectionWidget should operate on.

If input has multiple datasets they must have the same size in order to be manipulated at the same time. If inputMode() is not InputMode::Manual the input data will be changed automatically according to the setting.

◆ inputData()

const std::vector< Selectable * > & inputData ( )

inline

Returns the datasets the Selection widget is currently operating on.

Note: The return value may be a subset of the datasets originally passed to setInputData() because all input datasets must have the same size in order to be manipulated at the same time.

◆ isPlaying()

bool isPlaying ( )

Returns: true iff the playback is currently running.

The documentation for this class was generated from the following file:

ImFusion/GUI/SelectionWidget.h
