#include <ImFusion/Dicom/NuclearMedicineImageIOD.h>
PS 3.3 A.5 Nuclear Medicine Image IOD Does not support saving yet. More...
Public Member Functions | |
| NuclearMedicineImageIOD (DcmDataset &dataset, const OFString &sopClassUID) | |
| std::vector< Dicom::FrameDescriptor > | loadFrames () override |
| Loads all frames contained in this IOD. | |
| void | save (SharedImageSet &imageSet, int sharedImageIndex, int sliceIndex) override |
| Stores the general image descriptor and metadata of imageSet in the DICOM data set. | |
| void | savePixelData (SharedImageSet &imageSet, int sharedImageIndex, int sliceIndex) override |
| Writes the pixel data of imageSet in the DICOM data set. | |
| Public Member Functions inherited from ImFusion::Dicom::VolumetricImageIOD | |
| VolumetricImageIOD (DcmDataset &dataset, const OFString &sopClassUID) | |
| std::vector< FrameDescriptorSet > | sortAndGroupFrames (const std::vector< FrameDescriptor > &frames) const override |
| Sorts and groups the frame into volumetric groups if possible. | |
| std::vector< FrameDescriptor > | loadFrames () override |
| Loads all frames and initializes the matrix of each FrameDescriptor. | |
| void | save (SharedImageSet &imageSet, int sharedImageIndex, int sliceIndex) override |
| Stores the general image descriptor and metadata of imageSet in the DICOM data set. | |
| Public Member Functions inherited from ImFusion::Dicom::MultiFrameImageIOD | |
| MultiFrameImageIOD (DcmDataset &dataset, const OFString &sopClassUID) | |
| void | loadFrameData (const FrameDescriptor &desc, MemImage &image, int slice=-1) override |
| Loads the actual frame data into the given image. | |
| void | loadFrameProperties (const FrameDescriptor &desc, SharedImageSet &image) override |
| Loads any additional properties into the given image. | |
| Public Member Functions inherited from ImFusion::Dicom::IOD | |
| IOD (DcmDataset &dataset, const OFString &sopClassUID) | |
| Creates a new IOD representation using the given DcmDataset and SOP class UID. | |
| virtual void | checkErrors () const |
| Checks modules for errors and adds them to the list. | |
| template<typename T> | |
| const T * | searchModule () |
| Returns the first module of the given type or nullptr if no such module exists. | |
| DcmDataset & | dataset () override |
| Returns the dataset represented by this IOD. | |
| Public Member Functions inherited from ImFusion::Dicom::ModuleList | |
| const std::vector< const Module * > & | modules () const |
| List of all modules. | |
| Public Member Functions inherited from ImFusion::Dicom::ElementList | |
| const std::vector< ElementBase * > & | elements () const |
| List of all elements. | |
| Public Member Functions inherited from ImFusion::Dicom::ErrorRecorder | |
| virtual void * | registerErrorHandler (ErrorCallback handler) |
| Registers a new handler callback function. | |
| virtual void | unregisterErrorHandler (void *handler) |
| Removes a previously registered handler again. | |
| void * | forwardErrors (const ErrorRecorder *otherRecorder) |
| Convenient function to forward all errors registered to this recorder to another recorder. | |
| virtual void | registerError (const Error &error) const |
| Sends the given error to all error handler callbacks. | |
| void | registerError (Error::Code code, Error::Type type, const std::string &details, TagProxy tag=TagProxy()) const |
Public Attributes | |
| Dicom::Element< std::vector< std::string > > | imageType |
| Public Attributes inherited from ImFusion::Dicom::VolumetricImageIOD | |
| ImagePlane | imagePlane |
| Element< int > | echoNumbers |
| Element< int > | acquisitionNumber |
| Dicom::Element< std::vector< int > > | sliceVector |
| The following elements are used for sorting if numberOfFrames is greater 1: | |
| Dicom::Element< std::vector< int > > | angularViewVector |
| Public Attributes inherited from ImFusion::Dicom::MultiFrameImageIOD | |
| PixelSpacingCalibration | pixelSpacingCalib |
| ModalityLUT | modalityLut |
| Public Attributes inherited from ImFusion::Dicom::IOD | |
| const OFString | sopClassUID |
| DICOM SOP used. | |
| std::string | pathInfo |
| Optional information from which file this IOD was loaded from (only use for display purposes). | |
| CommonModule | common |
| ImagePixel | imagePixel |
| Element< int > | numberOfFrames |
| If this element exists and is larger than 1, multiple frames will be loaded regardless of the SOP Class defining it or not. | |
Additional Inherited Members | |
| Public Types inherited from ImFusion::Dicom::ErrorRecorder | |
| using | ErrorCallback = std::function<void(const Error&)> |
| Alias for a function to call for each error recorded. | |
| Protected Member Functions inherited from ImFusion::Dicom::ModuleList | |
| virtual void | addModule (const Module &m) |
| Adds a the module to the list. Should only be called by the Module constructor. | |
| virtual void | removeModule (const Module &m) |
| Protected Member Functions inherited from ImFusion::Utils::NotCopyable | |
| NotCopyable (NotCopyable &&) noexcept=default | |
| NotCopyable & | operator= (NotCopyable &&) noexcept=default |
| NotCopyable (const NotCopyable &)=delete | |
| NotCopyable & | operator= (const NotCopyable &)=delete |
| Protected Attributes inherited from ImFusion::Dicom::IOD | |
| DcmDataset & | m_dataset |
| Protected Attributes inherited from ImFusion::Dicom::ModuleList | |
| std::vector< const Module * > | m_modules |
| List of all modules. | |
| Protected Attributes inherited from ImFusion::Dicom::ElementList | |
| std::vector< ElementBase * > | m_elements |
| List of all elements. | |
|
overridevirtual |
Loads all frames contained in this IOD.
Might be multiple frames depending on numberOfFrames.
Reimplemented from ImFusion::Dicom::MultiFrameImageIOD.
|
overridevirtual |
Stores the general image descriptor and metadata of imageSet in the DICOM data set.
sharedImageIndex and sliceIndex describe which part of the image set should be stored.
Reimplemented from ImFusion::Dicom::MultiFrameImageIOD.
|
overridevirtual |
Writes the pixel data of imageSet in the DICOM data set.
sharedImageIndex and sliceIndex describe which part of the image set should be stored.
Reimplemented from ImFusion::Dicom::MultiFrameImageIOD.
