#include <ImFusion/GL/LinkPoseDeformable.h>
Links the pose of two or more data instances if there is deformation present. More...
Links the pose of two or more data instances if there is deformation present.
Public Member Functions | |
| LinkPoseDeformable (const DataList &data) | |
| Constructor with data list, pose linking starts right away. | |
| ~LinkPoseDeformable () override | |
| Destructor, stops the linking of the transformation. | |
| void | onDeformationChanged (const SharedImage *img) |
| Called when the deformation instance of an image has changed. | |
| void | onDeformationEvent (const DeformationEvent &event) |
| Called when deformation parameters have changed. | |
| DataList | getData () |
| List of data instances to link. | |
| std::vector< Gl3DObject * > & | getGlObjectsVector () |
| Vector of GlMeshes and GlPointClouds to be filled by controller. | |
| void | setPauseDefUpdating (bool b) |
| Turns updates based on the deformation field (expensive!) on or off. | |
| Public Member Functions inherited from ImFusion::LinkPose | |
| LinkPose (const DataList &data) | |
| Constructor with data list, pose linking starts right away. | |
| ~LinkPose () override | |
| Destructor, stops the linking of the transformation. | |
| void | compute () override |
| Unused compute method of the Algorithm interface. | |
| bool | paused () const |
| Returns the flag for temporarily pause linking to improve performance. | |
| void | setPaused (bool value) |
| Sets the flag for temporarily pause linking to improve performance. | |
| bool | accepts (const Data &data) const override |
| Checks whether the given Data instance is supported. | |
| void | add (Data &data) override |
| Add the given Data instance to the link. | |
| void | remove (Data *data) override |
| Remove the given Data instance from the link. | |
| std::vector< Data * > | data () const override |
| Return list of all linked Data instances. | |
| std::string | uiTitle () const override |
| Return a title of the link type for displaying in the UI. | |
| std::string | uiIconPath () const override |
| Return a path to an icon representing the link type to display in the UI. | |
| Public Member Functions inherited from ImFusion::Algorithm | |
| Algorithm () | |
| Default constructor will registers a single "compute" action that calls compute() and returns status(). | |
| virtual OwningDataList | takeOutput () |
| Return any new Data that was created by the Algorithm during the last call to compute(). | |
| virtual void | setProgress (Progress *progress) |
| Sets a Progress interface the algorithm can use to notify observers about its computing progress. | |
| Progress * | progress () const |
| Returns the progress interface if set. | |
| virtual int | status () const |
| Indicates the status of the last call to compute(). | |
| virtual bool | survivesDataDeletion (const Data *) const |
| Indicates whether the algorithm can handle (partial) deletion of the specified data, by default this checks whether the data is in the input list. | |
| const FactoryInfo & | factoryInfo () const |
| Returns the record describing how this Algorithm was instantiated by the AlgorithmFactory. | |
| void | setFactoryInfo (const FactoryInfo &value) |
| Sets the record describing how this Algorithm was instantiated by the AlgorithmFactory. | |
| Status | runAction (const std::string &id) |
| Run the action with name id if it exists. | |
| const std::vector< Action > & | actions () |
| Get a mapping from Action id to Action as registered in this algorithm. | |
| Public Member Functions inherited from ImFusion::Configurable | |
| virtual void | configure (const Properties *p) |
| Configure this object instance by de-serializing the given Properties. | |
| virtual void | configuration (Properties *p) const |
| Serialize the current object configuration into the given Properties object. | |
| virtual void | configureDefaults () |
| Retrieve the properties of this object, replaces values with their defaults and sets it again. | |
| void | registerParameter (ParameterBase *param) |
| Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration(). | |
| void | unregisterParameter (const ParameterBase *param) |
| Remove the given Parameter or SubProperty from the list of registered parameters. | |
| Configurable (const Configurable &rhs) | |
| Configurable (Configurable &&rhs) noexcept | |
| Configurable & | operator= (const Configurable &) |
| Configurable & | operator= (Configurable &&) noexcept |
| Public Member Functions inherited from ImFusion::SignalReceiver | |
| SignalReceiver ()=default | |
| Default constructor. | |
| SignalReceiver (const SignalReceiver &other) | |
| Copy constructor, does not copy any existing signal connections from other. | |
| SignalReceiver & | operator= (SignalReceiver rhs) |
| Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs. | |
| virtual | ~SignalReceiver () |
| Virtual destructor disconnects from all connected signals. | |
Static Public Member Functions | |
| static bool | createCompatible (const DataList &data, Algorithm **a=0) |
| Algorithm factory method. | |
| Static Public Member Functions inherited from ImFusion::LinkPose | |
| static void | registerHandler (LinkHandler handler) |
| Registers a new handler for linking a specific data type. Will be added at the end of the list, i.e. will take precedence over previously registered handlers. | |
| static bool | createCompatible (const DataList &data, Algorithm **a=0) |
| Algorithm factory method. | |
| Static Public Member Functions inherited from ImFusion::Algorithm | |
| static bool | createCompatible (const DataList &data, Algorithm **a=nullptr) |
| Factory function to check algorithm compatibility with input data and optionally instantiate it. | |
Protected Attributes | |
| std::shared_ptr< Deformation > | m_deformation |
| Deformation this algorithm listens to. | |
| std::vector< Gl3DObject * > | m_glObjects |
| GlMesh and GlPointCloud objects set by a controller to allow buffer updates. | |
| std::vector< Mesh * > | m_meshCopies |
| Copies of original meshes are needed to relate to original vertex positions. Created in constructor. | |
| std::vector< PointCloud * > | m_pointCloudCopies |
| Copies of original point clouds are needed to relate to original vertex positions. Created in constructor. | |
| bool | m_pauseDefUpdating |
| Flag whether deformation (expensive!) should be updated. | |
| Protected Attributes inherited from ImFusion::LinkPose | |
| std::vector< LinkItem > | m_links |
| list of Data links | |
| bool | m_block |
| Prevents redundant listener calls during update. | |
| bool | m_paused |
| temporarily pause linking to improve performance | |
| Protected Attributes inherited from ImFusion::Algorithm | |
| std::string | m_name |
| Algorithm name. | |
| Progress * | m_progress = nullptr |
| Non-owing pointer to a progress interface. May be a nullptr. | |
| FactoryInfo | m_factoryInfo = {} |
| Record describing how this algorithm was instantiated by the AlgorithmFactory. | |
| int | m_status = Status::Unknown |
| Algorithm status after last call to compute(). | |
| std::vector< Action > | m_actions |
| Map of key given by the id of the action, of the available actions of this algorithm. | |
| Protected Attributes inherited from ImFusion::Configurable | |
| std::vector< Param > | m_params |
| List of all registered Parameter and SubProperty instances. | |
Additional Inherited Members | |
| Public Types inherited from ImFusion::LinkPose | |
| typedef void(LinkPose::* | TransformationChangedFn) (const Data *data) |
| Public Types inherited from ImFusion::Algorithm | |
| enum | Status { Unknown = -1 , Success = 0 , Error = 1 , InvalidInput , IncompleteInput , OutOfMemoryHost , OutOfMemoryGPU , UnsupportedGPU , UnknownAction , AbortedByUser , User = 1000 } |
| Status codes. More... | |
| Public Attributes inherited from ImFusion::Algorithm | |
| Signal | signalOutputChanged |
| Signal should be emitted by Algorithms when their output/result has changed. | |
| Signal | signalParametersChanged |
| Signal should be emitted by Algorithms when their parameter configuration has changed. | |
| Public Attributes inherited from ImFusion::Configurable | |
| Signal | signalParametersChanged |
| Emitted whenever one of the registered Parameters' or SubPropertys' signalValueChanged signal was emitted. | |
| Protected Member Functions inherited from ImFusion::LinkPose | |
| void | transformationChanged (const Data *data) |
| Called when any of the data transformations have changed. | |
| Protected Member Functions inherited from ImFusion::Algorithm | |
| void | loadDefaults () |
| void | registerAction (const std::string &id, const std::string &guiName, const std::function< Algorithm::Status(void)> &action) |
| Register an action to be run via runAction. | |
| template<typename D> | |
| void | registerAction (const std::string &id, const std::string &guiName, Algorithm::Status(D::*action)(void)) |
| Template version of runAction that can be used with a pointer to a member function. | |
| void | registerAction (const Action &action) |
| Register an action. | |
| Protected Member Functions inherited from ImFusion::SignalReceiver | |
| void | disconnectAll () |
| Disconnects all existing connections. | |
| Static Protected Member Functions inherited from ImFusion::LinkPose | |
| static bool | registerDefaultHandlers () |
| Registers the default link handlers. | |
| Static Protected Attributes inherited from ImFusion::LinkPose | |
| static std::vector< LinkHandler > | m_handlers |
| List of link handlers. Handlers are search back to front and the first one that is compatible is used. | |
| static bool | m_defaultsAreRegistered |
| Whether registerDefaults was already called. | |
