Detailed Description

Set up a poly-rigid deformation on a volume and one or two AnatomicalStructureCollection objects.

The distance volumes are computed from the vertebrae stored in the source AnatomicalStructureCollection, which are used to define the rigid regions. This algorithm initialize a PolyRigidDeformation on the input CT volume based on the computed distance volumes with as many control points as the number of vertebrae. If two AnatomicalStructureCollection objects are provided, the first AnatomicalStructureCollection object is registered to the second AnatomicalStructureCollection object and this is used to set the initial parameters of the poly-rigid deformation.

Public Member Functions
	SpinePolyRigidDeformation (SharedImageSet &image, AnatomicalStructureCollection &spineSource, AnatomicalStructureCollection *spineDestination=nullptr)
	Constructor with a single volume, as well as a AnatomicalStructureCollection The (optional) destination AnatomicalStructureCollection is used to calculate initial transformations of rigid sections.

Public Member Functions inherited from Algorithm
	Algorithm ()
	Default constructor will registers a single "compute" action that calls compute() and returns status().

virtual void	setProgress (Progress *progress)
	Sets a Progress interface the algorithm can use to notify observers about its computing progress.

Progress *	progress () const
	Returns the progress interface if set.

virtual int	status () const
	Indicates the status of the last call to compute().

virtual bool	survivesDataDeletion (const Data *) const
	Indicates whether the algorithm can handle (partial) deletion of the specified data, by default this checks whether the data is in the input list.

const FactoryInfo &	factoryInfo () const
	Returns the record describing how this Algorithm was instantiated by the AlgorithmFactory.

void	setFactoryInfo (const FactoryInfo &value)
	Sets the record describing how this Algorithm was instantiated by the AlgorithmFactory.

Status	runAction (const std::string &id)
	Run the action with name `id` if it exists.

const std::vector< Action > &	actions ()
	Get a mapping from Action id to Action as registered in this algorithm.

Public Member Functions inherited from Configurable
virtual void	configure (const Properties *p)
	Configure this object instance by de-serializing the given Properties.

virtual void	configuration (Properties *p) const
	Serialize the current object configuration into the given Properties object.

virtual void	configureDefaults ()
	Retrieve the properties of this object, replaces values with their defaults and sets it again.

void	registerParameter (ParameterBase *param)
	Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration().

void	unregisterParameter (const ParameterBase *param)
	Remove the given Parameter or SubProperty from the list of registered parameters.

	Configurable (const Configurable &rhs)

	Configurable (Configurable &&rhs) noexcept

Configurable &	operator= (const Configurable &)

Configurable &	operator= (Configurable &&) noexcept

Public Member Functions inherited from SignalReceiver
	SignalReceiver ()=default
	Default constructor.

	SignalReceiver (const SignalReceiver &other)
	Copy constructor, does not copy any existing signal connections from other.

SignalReceiver &	operator= (SignalReceiver rhs)
	Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs.

virtual	~SignalReceiver ()
	Virtual destructor disconnects from all connected signals.

Public Attributes
Parameter< bool >	p_chamferDistance = {"chamferDistance", false, this}
	Use chamfer distance when computing the distance volume.

Parameter< bool >	p_sphereMode = {"sphereMode", false, this}
	Use sphere approximation instead of distance volumes to crudely approximate the inverse displacement.

Parameter< GlPolyRigidDeformation::Mode >	p_mode = {"mode", GlPolyRigidDeformation::Mode::FORWARD, this}

Parameter< int >	p_inversionSteps = {"inversionSteps", 50, this}

Public Attributes inherited from Algorithm
Signal	signalOutputChanged
	Signal should be emitted by Algorithms when their output/result has changed.

Signal	signalParametersChanged
	Signal should be emitted by Algorithms when their parameter configuration has changed.

Public Attributes inherited from Configurable
Signal	signalParametersChanged
	Emitted whenever one of the registered Parameters' or SubPropertys' `signalValueChanged` signal was emitted.

Methods implementing the Algorithm interface
void	compute () override
	Process the input AnatomicalStructureCollection, and setup control points and deformation instance.

OwningDataList	takeOutput () override
	Return any new Data that was created by the Algorithm during the last call to compute().

static bool	createCompatible (const DataList &data, Algorithm **a=nullptr)

Additional Inherited Members
Public Types inherited from Algorithm
enum	Status { Unknown = -1 , Success = 0 , Error = 1 , InvalidInput , IncompleteInput , OutOfMemoryHost , OutOfMemoryGPU , UnsupportedGPU , UnknownAction , AbortedByUser , User = 1000 }
	Status codes. More...

Static Public Member Functions inherited from Algorithm
static bool	createCompatible (const DataList &data, Algorithm **a=nullptr)
	Factory function to check algorithm compatibility with input data and optionally instantiate it.

Protected Member Functions inherited from Algorithm
void	loadDefaults ()

void	registerAction (const std::string &id, const std::string &guiName, const std::function< Algorithm::Status(void)> &action)
	Register an action to be run via runAction.

template<typename D>
void	registerAction (const std::string &id, const std::string &guiName, Algorithm::Status(D::*action)(void))
	Template version of runAction that can be used with a pointer to a member function.

void	registerAction (const Action &action)
	Register an action.

Protected Member Functions inherited from SignalReceiver
void	disconnectAll ()
	Disconnects all existing connections.

Protected Attributes inherited from Algorithm
std::string	m_name
	Algorithm name.

Progress *	m_progress = nullptr
	Non-owing pointer to a progress interface. May be a nullptr.

FactoryInfo	m_factoryInfo = {}
	Record describing how this algorithm was instantiated by the AlgorithmFactory.

int	m_status = Status::Unknown
	Algorithm status after last call to compute()

std::vector< Action >	m_actions
	Map of key given by the id of the action, of the available actions of this algorithm.

Protected Attributes inherited from Configurable
std::vector< Param >	m_params
	List of all registered Parameter and SubProperty instances.

Member Function Documentation

◆ createCompatible()

static bool createCompatible	(	const DataList &	data,
		Algorithm **	a = nullptr )

static

Factory method to create the algorithm

◆ compute()

void compute ( )

overridevirtual

Process the input AnatomicalStructureCollection, and setup control points and deformation instance.

Implements Algorithm.

◆ takeOutput()

OwningDataList takeOutput ( )

overridevirtual

Return any new Data that was created by the Algorithm during the last call to compute().

The default implementation will return an empty list.

Note: Since ownership of the data is transferred, you can call this method only once between calls to compute().

Reimplemented from Algorithm.

Member Data Documentation

◆ p_sphereMode

Parameter<bool> p_sphereMode = {"sphereMode", false, this}

Use sphere approximation instead of distance volumes to crudely approximate the inverse displacement.

The results of using the sphere mode should not be expected to be accurate.

The documentation for this class was generated from the following file:

SpinePlugin/include/ImFusion/Spine/SpinePolyRigidDeformation.h
