Detailed Description

GUI controller for adjusting visualization of meshes.

Public Slots
void	onChangeRenderMode ()

void	onChangeRenderMode (QAbstractButton *button)

void	onChangeManipulation ()

void	onChangeManipulation (QAbstractButton *button)

void	onChangeLighting ()

void	onChangeFaceNormals ()

void	onCenterInteraction ()

void	onViewMeshInfo ()

void	onChangeMaterialMode ()

void	onUpdateMaterialModeOptions ()

Public Member Functions
	MeshDataController ()
	Constructor with mesh data instance.

	~MeshDataController () override
	Destructor.

void	init () override
	Attach GUI to algorithm dock and initialize it.

void	onLocationChanged (Location newLocation) override
	Callback function called by the parent MainWindowBase/ControllerDecorator whenever the place was changed.

void	setMesh (GlMesh *glMesh)

GlMesh *	mesh () const

void	setPointCloud (GlPointCloud *glPointCloud)

GlPointCloud *	pointCloud () const

std::string	title () const override
	Returns the shown widget title if the controller is shown in a mode that supports this (e.g.

void	updateInput ()

Public Member Functions inherited from DataController
std::string	factoryName () const
	Returns the name used to identify this DataController in the factory.

void	setFactoryName (const std::string &factoryName)
	Sets the name used to identify this DataController in the factory.

std::vector< Location >	supportedLocations () const override
	Returns the list of locations in which this controller is allowed to be placed by the parent MainWindowBase.

Location	preferredLocation () const override
	Returns the preferred location in which the parent MainWindowBase should place this controller.

Public Member Functions inherited from Controller
void	setMainWindowBase (MainWindowBase *mw)
	Complete the initialization by providing the parent MainWindowBase instance hosting the controller by setting `m_main` and `m_disp` and eventually call init().

virtual void	onSelectedDataChanged (const DataList &)
	Called by MainWindowBase in the case that the selection in the data model has changed.

virtual void	onVisibleDataChanged (const DataList &)
	Called by MainWindowBase in the case that the currently visible data has changed.

Location	location () const
	Convenience function to query the current controller Location from the parent ControllerDecorator.

ControllerDecorator *	getDecorator () const
	Convenience function to return `m_main->getControllerDecorator(this)` if m_main is set or `nullptr` otherwise.

template<typename T>
T *	getDecorator () const
	Convenience function to `dynamic_cast` the return value of getDecorator() to a derived type.

Public Member Functions inherited from Configurable
virtual void	configure (const Properties *p)
	Configure this object instance by de-serializing the given Properties.

virtual void	configuration (Properties *p) const
	Serialize the current object configuration into the given Properties object.

virtual void	configureDefaults ()
	Retrieve the properties of this object, replaces values with their defaults and sets it again.

void	registerParameter (ParameterBase *param)
	Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration().

void	unregisterParameter (const ParameterBase *param)
	Remove the given Parameter or SubProperty from the list of registered parameters.

	Configurable (const Configurable &rhs)

	Configurable (Configurable &&rhs) noexcept

Configurable &	operator= (const Configurable &)

Configurable &	operator= (Configurable &&) noexcept

Public Member Functions inherited from SignalReceiver
	SignalReceiver ()=default
	Default constructor.

	SignalReceiver (const SignalReceiver &other)
	Copy constructor, does not copy any existing signal connections from other.

SignalReceiver &	operator= (SignalReceiver rhs)
	Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs.

virtual	~SignalReceiver ()
	Virtual destructor disconnects from all connected signals.

Static Public Member Functions
static bool	createCompatible (const DataList &data, DataController **a=0)
	Factory method to check and create this controller if applicable.

Static Public Member Functions inherited from DataController
static bool	createCompatible (const DataList &, DataController **=0)
	Factory interface for DataControllers: If data is compatible with data controller return true.

Protected Member Functions
void	onDataDeleted (const Data *data)

void	setEnabled (bool enabled)

void	updateWidgetsValue ()

void	resetInput ()

bool	supportsToolBar () const override
	Subclasses can return true if they support showing their GUI in Location::ToolBar.

MeshManipulator *	getMeshManipulator ()

Protected Member Functions inherited from SignalReceiver
void	disconnectAll ()
	Disconnects all existing connections.

Additional Inherited Members
Public Types inherited from Controller
enum class	Location : int { Unknown = -1 , Naked = 0 , PrimaryDock = 1 , SecondaryDock = 2 , Detached = 3 , ToolBar = 4 , UserLocation = 100 }
	Enumeration of possible placement/decoration options of a Controller. More...

Public Attributes inherited from Controller
Signal	signalTitleChanged
	Signal emitted when the title() has changed.

Public Attributes inherited from Configurable
Signal	signalParametersChanged
	Emitted whenever one of the registered Parameters' or SubPropertys' `signalValueChanged` signal was emitted.

Protected Attributes inherited from DataController
std::string	m_factoryName

Protected Attributes inherited from Controller
MainWindowBase *	m_main = nullptr
	The parent MainWindowBase instance hosting this Controller.

DisplayWidgetMulti *	m_disp = nullptr
	The main DisplayWidget instance, convenience shortcut for `m_main->display()`.

Protected Attributes inherited from Configurable
std::vector< Param >	m_params
	List of all registered Parameter and SubProperty instances.

Member Function Documentation

◆ init()

void init ( )

overridevirtual

Attach GUI to algorithm dock and initialize it.

Reimplemented from DataController.

◆ onLocationChanged()

void onLocationChanged ( Location newLocation )

overridevirtual

Callback function called by the parent MainWindowBase/ControllerDecorator whenever the place was changed.

Reimplemented from Controller.

◆ title()

std::string title ( ) const

overridevirtual

Returns the shown widget title if the controller is shown in a mode that supports this (e.g.

when in dock). Unless overridden, it returns the factory name.

Reimplemented from DataController.

◆ supportsToolBar()

bool supportsToolBar ( ) const

inlineoverrideprotectedvirtual

Subclasses can return true if they support showing their GUI in Location::ToolBar.

This interface is used by the default implementation of supportedLocations() and preferredLocation() to decide whether to use Location::ToolBar.

Reimplemented from DataController.

The documentation for this class was generated from the following file:

ImFusion/GUI/MeshDataController.h
