ImFusion C++ SDK 4.4.0
|
|
ImFusion C++ SDK 4.4.0
|
#include <ImFusion/GUI/AnnotationWidget.h>
Qt User interface for editing annotations managed by AnnotationModel. More...
Qt User interface for editing annotations managed by AnnotationModel.
Public Member Functions | |
| AnnotationWidget (MainWindowBase *mw) | |
| Construct annotation widget. | |
| ~AnnotationWidget () override | |
| Destructor. | |
| AnnotationModel * | model () |
| std::vector< InteractiveObject * > | selectedAnnotations (const Data *dataset, bool includeGlobal=true) const |
| void | createProjectiveObject (const std::vector< InteractiveObject * > &annotations, SharedImageSet &sis) |
| Creates a ProjectiveObject for a given annotation and adds it to the selected Fluoro image. | |
| void | moveAnnotationsToData (const std::vector< InteractiveObject * > &annotations, Data *data) |
| Move all passed annotations under the specified Data. If "data" is nullptr, move them to global annotations. | |
| void | setAutomaticallyLinkPoseWithParent (bool flag) |
| bool | getAutomaticallyLinkPoseWithParent () const |
| Public Member Functions inherited from ImFusion::ExpandableGroupBox | |
| ExpandableGroupBox (QWidget *parent=0) | |
| Creates an empty group box. | |
| QSize | sizeHint () const override |
| void | setWidget (QWidget *widget) |
| Sets the contained widget. | |
| QWidget * | widget () |
| Returns the contained widget if any or nullptr otherwise. | |
| QString | title () const |
| QIcon | icon () const |
| bool | isExpanded () const |
| bool | isResizable () const |
| void | setCollapsible (bool collapsible) |
| Sets if box is collapsible. | |
| bool | isCollapsible () |
| Returns if box is collapsible. | |
| void | setDraggable (bool value) |
| Sets the flag whether the box is draggable with the mouse when clicking on the top button. | |
| bool | isDraggable () const |
| Returns the flag whether the box is draggable with the mouse when clicking on the top button. | |
| int | count () const |
| Returns 1 if widget is set, 0 otherwise (required by the Qt designer plugin). | |
| int | currentIndex () const |
| Returns 0 (required by the Qt designer plugin). | |
| Public Member Functions inherited from ImFusion::SignalReceiver | |
| SignalReceiver ()=default | |
| Default constructor. | |
| SignalReceiver (const SignalReceiver &other) | |
| Copy constructor, does not copy any existing signal connections from other. | |
| SignalReceiver & | operator= (SignalReceiver rhs) |
| Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs. | |
| virtual | ~SignalReceiver () |
| Virtual destructor disconnects from all connected signals. | |
Protected Member Functions | |
| bool | eventFilter (QObject *obj, QEvent *event) override |
| Protected Member Functions inherited from ImFusion::SignalReceiver | |
| void | disconnectAll () |
| Disconnects all existing connections. | |
Additional Inherited Members | |
| Public Slots inherited from ImFusion::ExpandableGroupBox | |
| void | expand () |
| Expands the group box. | |
| void | collapse () |
| Collapses the group box. | |
| void | setExpanded (bool expanded) |
| Expands or collapses the group box (default: expanded). | |
| void | setResizable (bool isResizable) |
| Makes the group box vertical resizable (default: disabled). | |
| void | setTitle (const QString &title) |
| Sets the title of the group box. | |
| void | setIcon (const QIcon &icon) |
| Sets the icon of the group box. | |
| void | clearAndDeleteLater () |
| void | setVisible (bool visible) override |
| void | addAction (QAction *action) |
| Adds a new action to the right side of the expand/collapse button. | |
| void | removeAction (QAction *action) |
| Removes an action that was previously added with addAction. | |
| std::vector< QAction * > | actions () |
| Lists all actions. | |
| void | addPage (QWidget *widget) |
| Calls setWidget if no containing widget is set, does nothing otherwise (required by the Qt designer plugin). | |
| Signals inherited from ImFusion::ExpandableGroupBox | |
| void | expansionChanged (bool expanded) |
| void | resizableChanged (bool isResizable) |
| void | titleChanged (QString title) |
| void | iconChanged (QIcon icon) |
| void | actionAdded (QAction *action) |
| void | actionRemoved (QAction *action) |
| Properties inherited from ImFusion::ExpandableGroupBox | |
| QString | title |
| QIcon | icon |
| bool | expanded |
| bool | resizable |
