Detailed Description

Class storing a vector of AnatomicalStructureCollection objects.

Public Member Functions
	ASCSet (bool is2D=false)
bool	is2D () const
	Returns whether this ASCSet is 2D.
void	add (std::unique_ptr< AnatomicalStructureCollection > asc)
	Adds and anatomical structure collection.
AnatomicalStructureCollection *	get (int index=-1)
	Gets the specified (index >= 0) or focused (index == -1) anatomical structure collection.
const AnatomicalStructureCollection *	get (int index=-1) const
	Const version of previous method.
virtual DataList	children () const override
	CompoundData interface.
int	size () const override
	Returns the number of anatomical structure collections in this set.
Public Member Functions inherited from ImFusion::Data
	Data (const std::string &name="")
	Data (const Data &other)
Data &	operator= (const Data &other)
virtual	~Data ()
	Mandatory virtual destructor.
virtual Modality	modality () const
	Return the modality of this data.
const std::string &	name () const
	Return the name of this data.
void	setName (const std::string &name)
	Sets the name of this data.
virtual bool	isAnnotationType () const
	Return whether this data type is visualized through an annotation (e.g. mesh).
const DataComponentList &	components () const
	Returns the list of DataComponents for this data.
DataComponentList &	components ()
virtual void	setMatrixFromWorld (const mat4 &m)
	Set matrix mapping from the world coordinate system to the data coordinate system.
virtual void	setMatrixToWorld (const mat4 &m)
	Set matrix mapping from the data coordinate system to the world coordinate system.
virtual mat4	matrixFromWorld () const
	Get matrix mapping from the world coordinate system to the data coordinate system.
virtual mat4	matrixToWorld () const
	Get matrix mapping from the data coordinate system to the world coordinate system.
virtual mat4	matrix () const
	Return the transformation matrix.
virtual void	setMatrix (const mat4 &m)
	Set the transformation matrix.
Public Member Functions inherited from ImFusion::Selectable
	Selectable (const Selectable &)
	Selectable (Selectable &&)
Selectable &	operator= (const Selectable &)
Selectable &	operator= (Selectable &&)
virtual Selection	selection () const
virtual int	focus () const
virtual void	setSelection (const Selection &sel)
	Set the underlying selection.
virtual void	setFocus (int index)
	Set focus of the selection.
Public Member Functions inherited from ImFusion::SignalReceiver
	SignalReceiver ()=default
	Default constructor.
	SignalReceiver (const SignalReceiver &other)
	Copy constructor, does not copy any existing signal connections from other.
SignalReceiver &	operator= (SignalReceiver rhs)
	Assignment operator, disconnects all existing connections, does not copy any existing signal connections from rhs.
virtual	~SignalReceiver ()
	Virtual destructor disconnects from all connected signals.

Public Attributes
Signal	signalDataChanged
	This signal is connected to all child signalDataChanged signals.
Public Attributes inherited from ImFusion::Data
Signal< const Data * >	signalDeleted
	Signal emitted when this instance is deleted.
Signal< const Data * >	signalMatrixChanged
	Signal emitted when the transformation of this Data has changed.
Signal< std::string >	signalNameChanged
	Signal emitted when the name changed.
Public Attributes inherited from ImFusion::CompoundData
Signal< Data * >	signalChildAdded
	Signal emitted when a new Data instance has been added to children().
Signal< Data * >	signalChildMoved
	Signal emitted when a Data instance has changed its position in children().
Signal< Data * >	signalChildAboutToBeRemoved
	Signal emitted when a Data instance is about to be removed or taken from children().
Public Attributes inherited from ImFusion::Selectable
ProtectedSignal	signalSelectionChanged
	Signals that the selection or size might have changed.
Kind	kind () const override
	Data interface.
Pose::TransformationConvention	matrixConvention () const override
	Defines whether the internally stored matrices in derived classes map from or to the world coordinate system.
Geometry::AlignedBox	bounds () const override
	Returns the axis-aligned bounding box of this data in world space.
std::string	describe () const override
	Human readable description of the data for showing in the info bar.

Additional Inherited Members
Public Types inherited from ImFusion::Data
enum	Kind { UNKNOWN = 0 , IMAGE = 1 , VOLUME = 2 , IMAGESET = 3 , VOLUMESET = 4 , IMAGESTREAM = 5 , VOLUMESTREAM = 6 , POINTSET = 7 , SURFACE = 8 , TRACKINGSTREAM = 9 , LIVETRACKINGSTREAM = TRACKINGSTREAM , TRACKINGDATA = 10 , TREE = 11 , TENSOR = 12 , POLYDATASTREAM = 13 , STEREOIMAGESET = 14 , STEREOIMAGESTREAM = 15 , VOLUMETRICMESH = 16 }
	Kind of data. More...
enum	Modality { NA = 0 , XRAY = 1 , CT = 2 , MRI = 3 , ULTRASOUND = 4 , VIDEO = 5 , NM = 6 , OCT = 7 , LABEL = 8 , DISTANCE = 9 }
	Image modality of the data. More...
Static Public Member Functions inherited from ImFusion::Data
static std::string	modalityString (Data::Modality m)
	Return the name of an image modality.
static Data::Modality	stringToModality (const std::string &s)
	Returns the modality corresponding to a modality string or NA if nothing matches.
Protected Member Functions inherited from ImFusion::Data
void	swapWith (Data &other)
	Swaps the data and emits a matrix and name changed signal for both.
Protected Member Functions inherited from ImFusion::Utils::NotCopyable
	NotCopyable (NotCopyable &&) noexcept=default
NotCopyable &	operator= (NotCopyable &&) noexcept=default
	NotCopyable (const NotCopyable &)=delete
NotCopyable &	operator= (const NotCopyable &)=delete
Protected Member Functions inherited from ImFusion::SignalReceiver
void	disconnectAll ()
	Disconnects all existing connections.
Protected Attributes inherited from ImFusion::Data
mat4	m_matrix
	Transformation matrix.
std::recursive_mutex *	m_matrixMutex
	Used to internally synchronize access to the matrix of data.
DataComponentList	m_dataComponentList
	The list of DataComponents for this data.
Protected Attributes inherited from ImFusion::Selectable
std::mutex	m_selectionMutex
	Mutex protecting the selection.
Selection	m_sel

Member Function Documentation

◆ kind()

Kind ImFusion::ASCSet::kind ( ) const

inlineoverridevirtual

Data interface.

Implements ImFusion::Data.

◆ matrixConvention()

Pose::TransformationConvention ImFusion::ASCSet::matrixConvention ( ) const

inlineoverridevirtual

Defines whether the internally stored matrices in derived classes map from or to the world coordinate system.

Changes the behavior of the default implementations of matrixToWorld and matrixFromWorld.

Implements ImFusion::Data.

◆ bounds()

Geometry::AlignedBox ImFusion::ASCSet::bounds ( ) const

overridevirtual

Returns the axis-aligned bounding box of this data in world space.

Warning: Depending on the underlying data type this calling function may be computationally expensive! Do not call this method more often than needed, unless it is known that the caching behavior is implemented.

Implements ImFusion::Data.

◆ describe()

std::string ImFusion::ASCSet::describe ( ) const

overridevirtual

Human readable description of the data for showing in the info bar.

Reimplemented from ImFusion::Data.

◆ children()

virtual DataList ImFusion::ASCSet::children ( ) const

overridevirtual

CompoundData interface.

Implements ImFusion::CompoundData.

◆ size()

int ImFusion::ASCSet::size ( ) const

inlineoverridevirtual

Returns the number of anatomical structure collections in this set.

Implements ImFusion::Selectable.

The documentation for this class was generated from the following file:

AnatomyPlugin/include/ImFusion/AnatomyPlugin/ASCSet.h
