Detailed Description

template<typename OperandT>
class ImFusion::CT::DiagonalOperatorTpl< OperandT >

LinearOperator that multiplies each pixel by an ImageMath expression.

The matrix-representation of this operator would be a diagonal matrix.

Public Member Functions
	DiagonalOperatorTpl (const OperandT &operand, const SharedImageSet &domainRef, const SharedImageSet *rangeRef=nullptr)

Status	apply (const ExprBase &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const override
	Applies a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

Status	applyAdjoint (const ExprBase &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const override
	Applies the adjoint of a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

std::shared_ptr< ImageMath::ExprBase >	expr () const override
	returns a polymorphic expression for this operator

std::unique_ptr< LinearOperator >	clone () const override
	Factory method.

Public Member Functions inherited from LinearOperatorEvalInputExpr< false >
Status	apply (const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const override final

Status	applyAdjoint (const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const override final

	LinearOperator (const SharedImageSet domainRef, const SharedImageSet rangeRef=nullptr)
	Constructor with optional references for the domain and codomain (i.e. range) of the operator.

virtual Status	apply (const ExprBase &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const=0
	Applies a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

template<typename ImplType, typename ImplTypeOut>
Status	apply (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ImageMath::ExprBaseTpl< ImplTypeOut > *exprOut=nullptr) const

template<typename ImplType>
Status	apply (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const

virtual Status	applyAdjoint (const ExprBase &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const=0
	Applies the adjoint of a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

template<typename ImplType, typename ImplTypeOut>
Status	applyAdjoint (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ImageMath::ExprBaseTpl< ImplTypeOut > *exprOut=nullptr) const

template<typename ImplType>
Status	applyAdjoint (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const

Public Member Functions inherited from LinearOperator
	LinearOperator (const SharedImageSet domainRef, const SharedImageSet rangeRef=nullptr)
	Constructor with optional references for the domain and codomain (i.e. range) of the operator.

	~LinearOperator () override=0
	Destructor.

template<typename ImplType, typename ImplTypeOut>
Status	apply (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ImageMath::ExprBaseTpl< ImplTypeOut > *exprOut=nullptr) const

template<typename ImplType>
Status	apply (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const

template<typename ImplType, typename ImplTypeOut>
Status	applyAdjoint (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ImageMath::ExprBaseTpl< ImplTypeOut > *exprOut=nullptr) const

template<typename ImplType>
Status	applyAdjoint (const ImageMath::ExprBaseTpl< ImplType > &exprIn, const SharedImageSet &in, SharedImageSet &out, const ExprBase *exprOut=nullptr) const

Status	runBlock (Input &input, Output &output) override
	Applies the operator to the first element of input.

std::unique_ptr< LinearOperatorAdjointWrapper >	adjoint () const
	Creates an adjoint operator of this.

const SharedImageSet *	domainRef () const
	Getter for m_domainRef, can be nullptr if this is implicitly defined by the operator.

const SharedImageSet *	rangeRef () const
	Getter for m_rangeRef, can be nullptr if this is implicitly defined by the operator.

virtual std::unique_ptr< SharedImageSet >	createDomainSis () const
	Creates a SharedImageSet which is in the range of the operator.

virtual std::unique_ptr< SharedImageSet >	createRangeSis () const
	Creates a SharedImageSet which is in the range of the operator.

Eigen::MatrixXf	extractApplyMatrix () const
	Extracts a dense matrix representing this operator.

Eigen::MatrixXf	extractApplyAdjointMatrix () const
	Extracts a dense matrix representing this operator.

Public Member Functions inherited from Configurable
virtual void	configure (const Properties *p)
	Configure this object instance by de-serializing the given Properties.

virtual void	configuration (Properties *p) const
	Serialize the current object configuration into the given Properties object.

virtual void	configureDefaults ()
	Retrieve the properties of this object, replaces values with their defaults and sets it again.

void	registerParameter (ParameterBase *param)
	Register the given Parameter or SubProperty, so that it will be configured during configure()/configuration().

void	unregisterParameter (const ParameterBase *param)
	Remove the given Parameter or SubProperty from the list of registered parameters.

	Configurable (const Configurable &rhs)

	Configurable (Configurable &&rhs) noexcept

Configurable &	operator= (const Configurable &)

Configurable &	operator= (Configurable &&) noexcept

Additional Inherited Members
Public Types inherited from LinearOperator
using	ExprBase = ImageMath::ExprBase

Public Types inherited from Block
using	Input = DataList

using	Output = DataList

Public Attributes inherited from Configurable
Signal	signalParametersChanged
	Emitted whenever one of the registered Parameters' or SubPropertys' `signalValueChanged` signal was emitted.

Protected Attributes inherited from LinearOperator
const SharedImageSet *	m_domainRef = nullptr

const SharedImageSet *	m_rangeRef = nullptr

Protected Attributes inherited from Configurable
std::vector< Param >	m_params
	List of all registered Parameter and SubProperty instances.

Member Function Documentation

◆ apply()

template<typename OperandT>

Status apply	(	const ExprBase &	exprIn,
		const SharedImageSet &	in,
		SharedImageSet &	out,
		const ExprBase *	exprOut = nullptr ) const

inlineoverridevirtual

Applies a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

Computes \(exprOut(A * exprIn(in))\).

As \(A\) is linear, it can in principle be represented as a matrix. However we aim at large-scale implementations meaning that the corresponding matrix is typically to large to be kept in memory. We therefore only require an implementation of the matrix-vector product as opposed to an explicit representation.

Parameters

[in]	exprIn	Expression to which the linear operator is applied
[in]	in	Reference input to define the domain of the operator (this is neccessary as exprIn could be scalar).
[in,out]	out	Is overwritten with result of \(exprOut(A * exprIn(in))\).
[in]	exprOut	If set, this expression will be applied to the results after the operator was applied. If not set, treated as identity. `out` must contain ImageMath::Variable which will be substituted with the result of \(A * exprIn(in)\). In principle, this expression may contain `out` even if the values of `out` are then overwritten by this function. However, an operator may split up \(A\) into blocks, in which case the implemented LinearOperator must use checkOutExprAndCreateUpdateExprAndTmpOut to accumulate the result correctly.

Note: This method must be selection aware.

Implements LinearOperator.

◆ applyAdjoint()

template<typename OperandT>

Status applyAdjoint	(	const ExprBase &	exprIn,
		const SharedImageSet &	in,
		SharedImageSet &	out,
		const ExprBase *	exprOut = nullptr ) const

inlineoverridevirtual

Applies the adjoint of a linear operator \(A\), optionally pre/post-composing with an ImageMath expression.

Computes \(exprOut(A^\top * exprIn(in))\).

Parameters

[in]	exprIn	Expression to which the adjoint operator is applied.
[in]	in	Reference input defining the domain of the operator (this is neccessary, as exprIn can be a scalar expression).
[in,out]	out	Is overwritten with result of \(exprOut(A * exprIn(in))\).
[in]	exprOut	If set, this expression will be applied to the results after the operator was applied. If not set, treated as identity. `out` is expected to contain ImageMath::Variable which will be substituted with the result of \(A * exprIn(in)\). In principle, this expression may contain `out` even though `out` is overwritten by this function. However, an operator may split up \(A\) into blocks, in which case the implemented LinearOperator must use checkOutExprAndCreateUpdateExprAndTmpOut to accumulate the result correctly.

Note: This method must be selection aware.

Implements LinearOperator.

◆ expr()

template<typename OperandT>

std::shared_ptr< ImageMath::ExprBase > expr ( ) const

inlineoverridevirtual

returns a polymorphic expression for this operator

Implements DiagonalOperator.

◆ clone()

template<typename OperandT>

std::unique_ptr< LinearOperator > clone ( ) const

inlineoverridevirtual

Factory method.

Implements LinearOperator.

The documentation for this class was generated from the following file:

ImFusion/CT/Solver/DiagonalOperator.h
