ImFusion::US::ProcessUltrasoundParameters Struct Reference

#include <ImFusion/US/ProcessUltrasound.h>

Parameters controlling how ProcessUltrasound transforms each ultrasound frame. More...

Detailed Description

Parameters controlling how ProcessUltrasound transforms each ultrasound frame.

The options can be combined to update the physical spacing from the acquisition depth, crop the image to the US::FrameGeometry bounds, apply a fan mask, remove Doppler color information, and inpaint removed color pixels. extraCrop is only used when applyCrop is enabled and defines additional margins around the current US::FrameGeometry crop area.

Extra cropping margins

See also

• ProcessUltrasound
• US::FrameGeometry

Public Member Functions
bool	operator== (const ProcessUltrasoundParameters &other)

Public Attributes
bool	applyCrop = false
	If true, crop the image to the current frame geometry bounds.
bool	applyMask = false
	If true, mask pixels outside the current frame geometry.
bool	applyDepth = false
	If true, update the processed image spacing from depth and the current frame geometry depth.
double	depth = 0.0
	Current imaging depth as reported by the device, in millimeters.
int	removeColorThreshold = 0
	Doppler color removal threshold. Values greater than zero enable color pixel removal using ExtractDoppler.
bool	inpaint = false
	If true and applyMask is enabled, inpaint pixels removed by Doppler color removal before applying the fan mask.
vec4i	extraCrop = vec4i::Zero()
	Extra crop margins in pixels, ordered as left, right, top, and bottom.
bool	extraCropAbsolute = false
	If true, extraCrop margins are relative to the original image, otherwise they are applied on top of the fan crop.

---

The documentation for this struct was generated from the following file:

• ImFusion/US/ProcessUltrasound.h
